Configuring Dataverse Relationship Behaviors and Cascade Rules: Controlling Assign, Share, Delete, and Reparent Operations Across Parent-Child Table Hierarchies in Model-Driven Apps

Introduction

Here's a scenario that plays out in production Dataverse environments more often than anyone likes to admit: a salesperson leaves the company, so an admin reassigns their Account records to the new rep. Three weeks later, the support team notices that hundreds of open Cases still show the departed salesperson as owner. The data is inconsistent, the team is frustrated, and nobody can explain why the fix "only half worked." The culprit, almost always, is relationship behavior configuration — specifically, cascade rules that weren't set intentionally.

Cascade rules are the mechanism Dataverse uses to decide what happens to child records when something changes on the parent. When you delete a Project, do its Tasks disappear too? When you assign an Account to a new owner, do its Contacts come along? When you share an Opportunity with a team, does that access extend to the attached Quote records? These aren't abstract data-modeling questions — they have direct consequences for data integrity, security, and user experience inside your model-driven apps.

By the end of this lesson, you'll understand how each cascade behavior type works at the platform level, how to configure them intentionally for real-world parent-child relationships, and how to debug the downstream effects when behavior doesn't match expectations. We'll use a realistic project management data model throughout — Projects, Milestones, Tasks, and Attachments — to illustrate each scenario concretely.

What you'll learn:

• The five cascade actions (Assign, Share, Unshare, Reparent, Delete) and what triggers each one
• The available behavior options for each action and when to choose them
• How to configure relationship behaviors in Power Apps maker portal and via solution XML
• How Parental, Referential, and custom behavior presets translate into individual action settings
• How cascade rules interact with Dataverse security and record ownership
• Common misconfiguration patterns and how to diagnose and fix them

---

Prerequisites

You should be comfortable with Dataverse table relationships before diving in here. If you need a refresher on how one-to-many and many-to-many relationships work at a structural level, start with Designing a Dataverse Data Model: Relationships, Lookups, and Choice Columns and the deeper treatment in Configuring Dataverse Table Relationships in Model-Driven Apps: One-to-Many, Many-to-Many, and Cascade Behaviors Explained. You should also have a working understanding of Dataverse Security: Business Units, Security Roles, and Teams, since ownership and sharing concepts are central to how cascade rules function.

---

What Cascade Rules Actually Are (And Aren't)

Before you touch any configuration, it's worth building an accurate mental model of what cascade rules do.

Cascade rules are platform-level behaviors attached to a one-to-many relationship that execute automatically when certain operations are performed on the parent record. They are not Power Automate flows, not plug-ins, not business rules — they run synchronously at the database tier the moment the triggering operation commits. That distinction matters enormously for performance and predictability.

The five operations that can be cascaded are:

Operation	Triggered When...
Assign	A parent record's owner is changed
Share	A parent record is shared with a user or team
Unshare	A parent record's sharing is revoked
Reparent	A child record's lookup value is changed to point to a different parent
Delete	A parent record is deleted

Each operation has its own behavior setting, and they're independent of each other. You can configure Delete to cascade while Share does nothing, or vice versa. Understanding each one separately is the key to intentional configuration.

---

The Behavior Options: What Each One Means

For each cascade action, Dataverse offers a set of behavior options. Not all options are available for every action, but understanding the full vocabulary first will make the configuration choices clearer.

Cascade All

Every child record that belongs to the parent gets the same operation applied. If you assign a Project to a new owner, all Milestones and Tasks owned by the old Project owner get reassigned to the new one.

Cascade Active

Only child records in an active state get the cascade. Completed, cancelled, or inactive child records are left as-is. This is extremely useful when you want historical records to preserve their original ownership for audit purposes.

Cascade User-Owned

The cascade applies only to child records that are owned by the same user as the parent. Child records that were individually assigned to other users are left alone. This is the most nuanced and often the most correct setting for real-world scenarios where team members have been assigned individual tasks from a shared project.

No Cascade (Do Nothing / Restrict)

Nothing happens to child records when the parent changes. For Delete specifically, this option comes in two flavors:

• Restrict: The parent cannot be deleted if child records exist. The platform enforces referential integrity by blocking the deletion.
• Remove Link: The parent can be deleted, and the child records' lookup column is set to null, orphaning them.

Cascade None (for Share/Unshare/Reparent)

No propagation occurs. Each child record's sharing, linking, or ownership is managed independently.

---

The Three Relationship Behavior Presets

When you create a 1:N relationship, Dataverse offers three named behavior presets before letting you go fully custom. Understanding what these actually configure under the hood prevents a lot of confusion.

Parental Behavior

This is the "tight coupling" preset. Every cascade action is set to Cascade All. The child is fully dependent on the parent — whatever happens to the parent happens to all children, without exception.

Action	Setting
Assign	Cascade All
Share	Cascade All
Unshare	Cascade All
Reparent	Cascade All
Delete	Cascade All

Use Parental when child records genuinely have no independent existence. The relationship between Invoice and Invoice Line Item is the canonical example — a line item is meaningless without its invoice. In our project management model, Project → Milestone is a good candidate: a milestone that isn't associated with any project is useless data.

Referential Behavior

This is the "loose coupling" preset. The relationship enforces that the parent exists (referential integrity), but no cascade propagation occurs.

Action	Setting
Assign	No Cascade
Share	No Cascade
Unshare	No Cascade
Reparent	No Cascade
Delete	Restrict

Use Referential when the child can exist somewhat independently and you want to prevent orphaning by blocking deletion of a parent that still has children. A Contact linked to an Account is the standard example — the Contact can be managed separately, and you shouldn't be able to delete an Account with active Contacts without explicitly handling them first.

Referential, Restrict Delete

This is a variant where Delete is set to Restrict but the other four actions also propagate. It's less commonly used as a preset because most scenarios that want restrict-on-delete usually don't want full cascades elsewhere. You'll typically find yourself in Custom territory here.

Custom Behavior

Custom lets you set each of the five actions independently. This is where most mature data models end up, because real-world business rules rarely fit neatly into "everything cascades" or "nothing cascades."

---

Configuring Relationship Behaviors in the Maker Portal

Let's walk through the actual configuration steps using our project management model.

Scenario: You have a crm_project table and a crm_task table connected by a 1:N relationship via a crm_projectid lookup on the Task table. You want Tasks to:

• Be reassigned when the Project is reassigned, but only Tasks still owned by the same user as the Project (Assign → Cascade User-Owned)
• Be deleted if the Project is deleted (Delete → Cascade All)
• NOT inherit sharing changes automatically — task access is managed separately (Share → No Cascade)

To configure this:

1. Open make.powerapps.com and navigate to your solution.
2. Open the crm_project table (the "one" side of the relationship).
3. Select the Relationships tab from the left panel.
4. Find the relationship to crm_task and click the three-dot menu, then Edit.
5. In the relationship editor, expand the Advanced options section (sometimes labeled More options depending on your interface version).
6. You'll see five dropdown selectors, one per cascade action.
7. Set Assign to Cascade User-Owned.
8. Set Delete to Cascade All.
9. Set Share, Unshare, and Reparent to No Cascade.
10. Click Done, then Save table.

---

Understanding Each Action in Depth

Assign: Ownership Propagation Done Right

The Assign cascade is about record ownership, which in Dataverse is the ownerid column present on all user-owned tables. When a parent record is reassigned, the cascade determines whether child records follow.

In our project management model, consider: a Project Manager is reassigned when they move to a different department. The admin reassigns their Projects to the new PM. With Cascade All, every Task — including ones the old PM had already individually delegated to junior team members — gets yanked back and reassigned to the new PM. That's almost certainly wrong.

Cascade User-Owned is the right call here. It says: "Only reassign Tasks that are still owned by the same person who owned the Project." Tasks that a team member was specifically assigned to stay with that person. This respects intentional individual assignments while still catching the "forgotten" tasks that were never explicitly delegated.

The tricky part: Cascade User-Owned compares the child's current owner to the parent's pre-change owner, not the post-change owner. So if Project is owned by Alice and you reassign it to Bob, Cascade User-Owned will find all Tasks owned by Alice and reassign them to Bob. Tasks owned by Carol or David stay put.

Share and Unshare: Access Without Ownership Transfer

Sharing is Dataverse's mechanism for granting access to records without transferring ownership. As covered in detail in Column-Level Security and Record Sharing in Dataverse, you can share a specific record with a user or team at a given access level.

When you share a Project record with the leadership team so they can view progress, do you also want them to see every Task? That depends entirely on your security model.

If your security roles already grant leadership read access to all Task records within their business unit, sharing the Project with them is redundant for Tasks — no cascade needed (No Cascade). But if Task records are scoped very tightly and the only way for leadership to see them is through explicit sharing of the parent Project, then Cascade All on Share is the right choice.

The symmetric rule applies to Unshare. If you cascade Share, you almost always want to cascade Unshare with the same setting. Sharing a Project with someone and then revoking that share while they retain access to all the Tasks underneath is a security hole.

Reparent: When a Child Changes Parents

Reparent fires when a user changes the value of the lookup field on the child record — essentially moving a Task from one Project to another. The cascade behavior here controls what happens to ownership and sharing when that move occurs.

With Cascade All on Reparent: when a Task is moved to a new Project, the Task's owner is updated to match the new Project's owner, and all sharing on the Task is replaced with the new Project's sharing.

With No Cascade on Reparent: moving a Task to a different Project changes only the lookup value. The Task keeps its current owner and its existing sharing configuration, regardless of what the new Project looks like.

For most scenarios involving task reassignment in project management, No Cascade on Reparent is correct. A task being moved to a different project is an administrative action, not an ownership transfer event. The person who was doing the task is still doing it.

Delete: The Most Consequential Setting

Delete cascade is where data loss lives. Get this wrong and you can either:

1. Delete a parent and silently wipe hundreds of child records (Cascade All without warning)
2. Try to delete a parent and get blocked by an opaque error because children exist (Restrict without explanation to the user)

For our project management model:

• Project → Milestone: Cascade All. A milestone without a project is orphaned data.
• Milestone → Task: Cascade All. Same reasoning.
• Task → Attachment: Cascade All. Attachment files stored in Dataverse should go with their task.
• Project → Time Entry (if Time Entries are used for billing): Restrict. You don't want to destroy billing records just because a project is closed or deleted. Force the admin to explicitly handle time entries first.

This layered approach — cascading through the operational hierarchy but restricting at the financial/audit boundary — is a pattern you'll see in well-designed Dataverse solutions.

---

Configuring via Solution XML: The Practitioner's Shortcut

When you're migrating solutions between environments or configuring relationships at scale, knowing the underlying XML is valuable. Relationship behaviors are stored in the solution's customizations.xml inside the relationship definition.

Here's what a custom behavior configuration looks like for the Project-to-Task relationship:

<EntityRelationship Name="crm_project_crm_task">
  <EntityRelationshipType>OneToMany</EntityRelationshipType>
  <IsHierarchical>0</IsHierarchical>
  <ReferencingEntityName>crm_task</ReferencingEntityName>
  <ReferencedEntityName>crm_project</ReferencedEntityName>
  <CascadeAssign>UserOwned</CascadeAssign>
  <CascadeDelete>All</CascadeDelete>
  <CascadeReparent>NoCascade</CascadeReparent>
  <CascadeShare>NoCascade</CascadeShare>
  <CascadeUnshare>NoCascade</CascadeUnshare>
  <IsValidForAdvancedFind>1</IsValidForAdvancedFind>
  <ReferencingAttributeName>crm_projectid</ReferencingAttributeName>
  <RelationshipDescription>
    <Descriptions />
  </RelationshipDescription>
  <CascadeRollupView>NoCascade</CascadeRollupView>
  <EntityRelationshipRoles>
    <EntityRelationshipRole>
      <NavPropName>crm_project_crm_task</NavPropName>
      <RelationshipRoleType>0</RelationshipRoleType>
    </EntityRelationshipRole>
    <EntityRelationshipRole>
      <NavPropName>crm_projectid_crm_project</NavPropName>
      <RelationshipRoleType>1</RelationshipRoleType>
    </EntityRelationshipRole>
  </EntityRelationshipRoles>
</EntityRelationship>

The cascade values in XML use these string mappings:

UI Label	XML Value
Cascade All	All
Cascade Active	Active
Cascade User-Owned	UserOwned
No Cascade	NoCascade
Restrict	Restrict
Remove Link	RemoveLink

---

How Cascade Rules Interact with Security

This is the dimension that catches practitioners off guard. Cascade rules and security roles interact in ways that can produce unexpected results — records that should be reassigned aren't, or records get shared more broadly than intended.

Cascade Assign and Security Boundaries

When Cascade All fires for an Assign operation, Dataverse reassigns all child records regardless of whether the new owner has a security role that grants access to those child table records. The records get a new ownerid — access is determined at runtime when the new owner tries to open them.

This means you can assign a Project to someone who has no security role for the Task table, and all the Tasks will now show that person as owner. When they try to view those tasks, they'll get an access error. The cascade executed successfully — the security enforcement happens separately.

Cascade Share and Business Unit Scoping

When Cascade All fires for Share, Dataverse creates principalobjectaccess records (the internal sharing table) for every child record. This can produce a very large number of sharing records if you have many child records. In large environments, aggressive use of Share cascading can cause the principalobjectaccess table to grow significantly, which has query performance implications.

For solutions where sharing is needed at scale, consider whether designing Dataverse hierarchical relationships and rollup security might be a better approach than sharing cascades. Hierarchical security lets managers automatically inherit access to records owned by subordinates, which can replace a large chunk of explicit sharing logic.

The Merge Operation

There's a sixth operation you won't find in the cascade configuration UI: Merge. When you merge two parent records (common with Accounts and Contacts in Sales scenarios), Dataverse uses a fixed behavior: child records are reparented to the surviving record, and the behavior for the Reparent cascade setting applies. If you have Reparent set to Cascade All, the merge will also reassign all children to the surviving record's owner. Be aware of this when merging in production.

---

Hands-On Exercise

Let's build and test a realistic cascade configuration for a three-level hierarchy.

Data model:

• crm_project (parent) → crm_milestone (child) → crm_task (grandchild)

Business requirements:

1. Deleting a Project deletes all its Milestones and Tasks
2. Assigning a Project to a new PM only reassigns Milestones and Tasks that are currently owned by the old PM
3. Sharing a Project with the leadership team also shares all Milestones and Tasks
4. Moving a Task to a different Milestone should not change the Task's owner

Step 1: Configure Project → Milestone Relationship

Navigate to the crm_project table, open Relationships, edit the relationship to crm_milestone, and set:

• Assign: Cascade User-Owned
• Share: Cascade All
• Unshare: Cascade All
• Reparent: No Cascade
• Delete: Cascade All

Save the table.

Step 2: Configure Milestone → Task Relationship

Navigate to the crm_milestone table, open Relationships, edit the relationship to crm_task, and set the same values as Step 1.

Step 3: Test the Delete Cascade

Create a test Project with two Milestones. Under each Milestone, create two Tasks. You should have 1 Project, 2 Milestones, 4 Tasks.

Delete the Project. Navigate to the Task view — filter to show all records including inactive. All four Tasks should be gone. Navigate to Milestones — both should be gone.

Step 4: Test the Assign Cascade with User-Owned

Create a new Project owned by User A. Create two Milestones both owned by User A. Create four Tasks: two owned by User A, one owned by User B, one owned by User C.

Assign the Project to User D.

Expected result:

• Both Milestones are now owned by User D (they were owned by User A, who was the Project owner)
• Two Tasks owned by User A are now owned by User D
• Task owned by User B stays with User B
• Task owned by User C stays with User C

Verify by checking the Tasks view filtered by owner.

Step 5: Test the Share Cascade

Share the Project with a test team at Read access level.

Navigate to Advanced Settings → Security → Access Teams (or use the sharing dialog in the record). After sharing the Project, check one of the Tasks. Open the task record and select Share from the command bar. The sharing dialog should show the test team already has Read access — this was inherited from the Project cascade.

---

Common Mistakes & Troubleshooting

Mistake 1: Assuming Cascade Happens Instantly for Large Datasets

Cascade operations are synchronous for small record sets, but when a parent has thousands of children, Dataverse processes the cascade asynchronously. The API call returns success, but child records are updated in batches over the next several minutes. Users who check immediately after a large assign operation may see mixed ownership states — some children updated, some not yet.

Diagnosis: Check the System Jobs view in the maker portal (Settings → System Jobs). Filter by status "In Progress" or "Waiting." You'll see the cascade operation listed.

Fix: Communicate to users that large cascade operations take time. Add a view or dashboard that makes ownership state visible so the team can monitor completion.

Mistake 2: Parental Behavior on Independently Managed Records

A team configures a Customer → Support Case relationship as Parental because it seems logical — Cases belong to Customers. But then they assign Cases to individual support agents and share Cases with specialist teams. Every time a Customer is reassigned to a new account owner, all their Cases silently change owner too.

Diagnosis: Check the relationship behavior. If it's Parental (all cascades set to Cascade All), the Assign and Share cascades are probably doing more than intended.

Fix: Switch Assign to Cascade User-Owned and Share to No Cascade. Cases that were individually assigned to agents will stay with those agents.

Mistake 3: Restrict Delete with No User-Facing Explanation

An admin configures a Project → Time Entry relationship with Delete set to Restrict. When a user tries to delete a completed Project, they get a generic error. They escalate, the helpdesk can't explain it, and trust in the system erodes.

Diagnosis: Look at the relationship behavior for the entity that's blocking deletion. A Restrict setting is correct behavior — the problem is the UX.

Fix: Add a subgrid on the Project form showing Time Entries, so users can see the dependency. Add a business rule or notification that proactively warns before deletion. Consider adding an "Archive" status so Projects can be deactivated (which doesn't trigger Delete cascade) rather than deleted.

Mistake 4: Changing Behaviors on Relationships with Existing Relationships

You change a relationship from Referential (No Cascade on Delete) to Parental (Cascade All on Delete). Existing records are unaffected — the new behavior applies only to future operations. Existing child records still reference the parent as before. There's no retroactive enforcement.

Diagnosis: After changing behaviors, run a test by performing the operation on a test record. If children don't cascade, double-check that the change was saved (publish) and that you're testing the right relationship.

Fix: No fix needed — this is expected behavior. Behavior changes are not retroactively applied. If you need to "backfill" the effect of a behavior change (e.g., reassigning all children of a recently reassigned parent), you'll need a Power Automate flow or bulk update via dataflow. See Importing and Migrating Data into Dataverse: Excel Import, Dataflows, and Upserts for bulk update patterns.

Mistake 5: Forgetting the CascadeRollupView Setting

In the solution XML, you may notice a <CascadeRollupView> element. This controls whether changes to child records trigger recalculation of rollup columns on the parent. If you have rollup columns that aggregate child data (like total hours across Tasks for a Project), this setting must be All for those rollups to stay current.

Diagnosis: Rollup column values on the parent look stale. Check the CascadeRollupView setting in the relationship XML.

Fix: Set CascadeRollupView to All in the relationship definition. Note that this is separate from the five user-visible cascade actions and is only accessible via solution XML or the SDK — the maker portal doesn't surface it directly. For more on rollup columns, see Formula Columns and Rollup Columns in Dataverse: Calculated Data Without Code.

---

Relationship Behaviors Across Solution Layers

One underappreciated complexity: if your solution is deployed as a managed solution on top of a base solution, relationship behaviors defined in the base layer can be overridden in a customization layer — but only if the base solution publisher has marked them as customizable.

When you import a managed solution that changes a relationship behavior, the behavior change applies immediately to all existing records and future operations. This is a breaking change if downstream solutions depend on the original behavior.

---

Building a Cascade Decision Framework for Your Data Model

Rather than configuring behaviors relationship by relationship without a plan, use this framework:

1. Classify each relationship by child independence.

• Fully dependent (child has no meaning without parent) → Start with Parental, adjust Share if needed
• Semi-independent (child exists in context of parent but can be managed separately) → Custom with Delete = Restrict, Assign = User-Owned
• Independent with link (parent is just a category/classification) → Referential, No Cascade on everything except Delete = Restrict

2. Map your ownership model.

• Who owns parent records? Who owns child records?
• Are they typically the same person, or does child ownership diverge?
• If they diverge, Cascade User-Owned is almost always right for Assign

3. Define your deletion policy.

• Is child data operationally valid without the parent? → Remove Link (rare, use cautiously)
• Does deleting the parent make the child meaningless? → Cascade All
• Does the child have independent value (billing, audit, compliance)? → Restrict

4. Define your sharing policy.

• Does sharing the parent grant the same access you want on children? → Cascade All
• Is child access managed by security role rather than sharing? → No Cascade

5. Document the decisions in your solution design. Add a relationship matrix to your data model documentation — table name, related table, and the five cascade settings. This becomes invaluable during maintenance when someone asks "why can't I delete this record?" six months after go-live.

---

Summary & Next Steps

Cascade rules are one of those configuration areas where small decisions have large consequences. The five actions — Assign, Share, Unshare, Reparent, and Delete — each control a distinct dimension of what it means for a child record to follow its parent through the lifecycle of the data. Configuring them thoughtlessly (or leaving them at defaults) is the source of a surprisingly large number of production data quality and security issues.

The key takeaways from this lesson:

• Parental means everything cascades. Use it only when children are truly dependent and cannot be independently managed.
• Referential means nothing cascades and deletion is blocked if children exist. It's the safe default for loosely coupled relationships.
• Cascade User-Owned for Assign is almost always more correct than Cascade All in team environments where tasks get individually delegated.
• Delete = Restrict at financial or audit boundaries prevents data loss without blocking all deletion.
• Changes to relationship behaviors apply only to future operations — they're not retroactive.
• Test cascade behaviors in non-production before deploying to environments with real data.

From here, consider exploring how server-side logic can complement cascade rules. For complex scenarios where cascade rules alone aren't sufficient — for example, when you need to conditionally cascade based on a field value — Configuring Dataverse Table Event Plugins and Real-Time Workflows in Model-Driven Apps covers how to enforce that kind of logic at the data layer. Cascade rules and plug-ins work best as complements, not substitutes.
