Designing Dataverse Hierarchical Relationships and Rollup Security: Configuring Parent-Child Table Hierarchies, Hierarchical Security Models, and Hierarchy Visualizations in Model-Driven Apps

Introduction

Imagine you're building a field service management application for a company that operates across six regional divisions, each with district managers overseeing multiple teams, each team managing dozens of work orders, and every work order potentially spawning child tasks. Your data model has to represent that organizational reality faithfully — not just as a flat list of records with lookup fields, but as a true tree structure where the system understands ancestry and descent. Now add the security requirement: a regional director should automatically see every record beneath them in the hierarchy without you manually assigning permissions to every row. That's the problem hierarchical relationships in Dataverse were designed to solve.

Most Power Platform developers understand one-to-many relationships and lookup columns. Far fewer understand the distinction between a standard self-referential lookup and a designated hierarchy relationship, the implications that designation has on query behavior, what hierarchical security actually does versus what people assume it does, and how the hierarchy visualizer control in model-driven apps surfaces all of this to end users. The gaps in this knowledge lead to subtle security holes, confusing UX, and rollup calculations that don't behave the way you'd expect.

By the end of this lesson, you'll be able to design and implement true hierarchical table structures in Dataverse, configure the hierarchical security model so that record access propagates correctly up and down the tree, use Dataverse queries that leverage hierarchy traversal, build hierarchy visualizations that make the tree navigable for users, and reason clearly about the architectural trade-offs involved in each decision.

What you'll learn:

• How to configure a self-referential lookup as a designated hierarchy relationship and what that designation actually does under the hood
• The difference between hierarchical security and standard role-based security, including when hierarchy security doesn't protect what you think it does
• How rollup columns interact with hierarchical data and the performance implications at scale
• How to surface the hierarchy visualizer control in model-driven apps and configure it meaningfully
• Advanced querying patterns using the Under and EqualUserOrUserHierarchy operators in FetchXML and the Web API

---

Prerequisites

This lesson assumes you are comfortable with Dataverse fundamentals — tables, columns, and the relationship system. You should understand how one-to-many relationships work and how cascade behaviors affect related records. If you need to solidify that foundation first, read through Configuring Dataverse Table Relationships in Model-Driven Apps: One-to-Many, Many-to-Many, and Cascade Behaviors Explained before continuing.

You should also have basic familiarity with Dataverse security roles and business units. The Dataverse Security: Business Units, Security Roles, and Teams lesson covers those foundations.

---

Understanding What "Hierarchy" Actually Means in Dataverse

Before touching any configuration, you need to understand what Dataverse means by hierarchy — because it's more specific than a generic parent-child relationship.

In Dataverse, any table can have a self-referential one-to-many relationship. That means the Account table, for example, has a lookup back to Account — one account can be the parent of many child accounts. This is technically a parent-child relationship, and it exists on the Account table by default (the parentaccountid column). But a lookup column on its own doesn't give Dataverse any special awareness that a hierarchy exists.

The critical step is designating a specific self-referential relationship as the hierarchy relationship for that table. A table can have many self-referential lookups, but only one can be the designated hierarchy at any time. Once designated, that relationship unlocks:

1. Hierarchy query operators — FetchXML and the Web API gain Under, Not Under, EqualUserOrUserHierarchyAndTeams, and related conditions that traverse the tree
2. Hierarchical security — security roles can be granted with hierarchy access depth applied
3. The hierarchy visualizer — the tree view control in model-driven apps becomes available on that table's views

Self-Referential Relationships vs. Cross-Table Hierarchies

Dataverse hierarchy designation only works on self-referential relationships — a lookup from a table back to itself. You cannot designate a relationship between two different tables (e.g., Region → District → Territory) as a Dataverse hierarchy in the sense that unlocks hierarchy security and the visualizer.

For multi-table hierarchies, you need a different architectural approach: either flatten your hierarchy into a single self-referential table (using a "type" or "level" column to distinguish levels), or accept that you'll handle the cross-table aggregation logic yourself. Both approaches are valid, and we'll cover the trade-offs in detail later.

The self-referential constraint catches people off guard, especially those coming from SQL backgrounds where hierarchical CTEs work across any columns. In Dataverse, the hierarchy engine is specifically designed around the single-table tree pattern.

---

Configuring a Self-Referential Hierarchy Relationship

Let's build a concrete example. Suppose you're modeling an organizational unit hierarchy for a professional services firm: each Organizational Unit record can have a parent Organizational Unit, creating a tree from the company root down to individual teams.

Step 1: Create the Self-Referential Relationship

Navigate to make.powerapps.com, open your solution, select your table (we'll call it crf_organizationalunit), and go to the Relationships section.

Select Add relationship, then Many-to-one. In the "Related table" dropdown, select the same table — Organizational Unit. Give the relationship a meaningful schema name, such as crf_organizationalunit_parentunit. The lookup column this creates will store the GUID of the parent record.

Set the relationship behavior. For a hierarchy, you typically want:

• Reparenting: Referential (no cascade) — reparenting an org unit shouldn't automatically reparent its children
• Delete: Restrict — you shouldn't be able to delete a parent unit while it still has children

Save the relationship.

Step 2: Designate the Relationship as the Hierarchy

After the relationship is created, find it in the relationships list. Select it to open the relationship editor. You'll see a checkbox or toggle labeled Hierarchical (in the modern maker portal it appears as "Set as hierarchical"). Enable it and save.

You can also do this through the classic solution explorer: navigate to the table, open Relationships, find your self-referential relationship, double-click it, and check the Hierarchical checkbox.

Once designated, Dataverse updates the EntityMetadata for the table. If you retrieve the table's metadata via the Web API, you'll see hierarchyrelationshipname populated with your relationship's schema name.

Step 3: Configure the Lookup Column on Forms

The lookup column created by the relationship (e.g., crf_parentunitid) needs to appear on the Organizational Unit form so users can assign parents. Navigate to your table's main form.

When placing this lookup on the form, consider two things. First, add filtering to prevent circular references in the UI — a record should not be able to select itself or its own descendants as its parent. You can apply a view filter on the lookup, though this doesn't prevent circular references at the data layer (that requires a plugin or business rule). Second, consider making the field optional (not business required) to accommodate root-level units that have no parent.

For more on form design patterns, see Designing Model-Driven Forms: Sections, Tabs, Subgrids, and Quick View Forms for guidance on placing and organizing lookup fields effectively.

---

Hierarchical Security: How It Actually Works

Hierarchical security is one of the most misunderstood features in the Power Platform security model. Let's establish the mental model correctly before diving into configuration.

The Two Components of Hierarchical Security

Hierarchical security in Dataverse comes in two distinct flavors:

1. Manager hierarchy — based on the systemuser table's built-in parentsystemuserid self-referential relationship. Users who are managers of other users (as expressed by this relationship) gain access to records owned by users beneath them in the manager chain.

2. Position hierarchy — based on a separate Position table, where users are assigned to positions and positions form their own tree. A user at a higher position gains access to records owned by users at lower positions.

Both flavors apply only to the systemuser hierarchy — that is, they control which user's owned records another user can see. They do not apply to arbitrary table hierarchies you create.

Configuring the Manager Hierarchy

To enable manager-based hierarchical security:

1. In the Power Platform Admin Center, navigate to your environment's Settings.
2. Under Users + Permissions, select Hierarchy security.
3. Enable Turn on Hierarchy Modeling and choose Manager hierarchy.
4. Set the Depth value. This controls how many levels below a manager in the hierarchy will have their records visible to managers above. A depth of 3 means a VP can see records owned by their direct reports, their direct reports' reports, and one level further down.

The systemuser manager chain is configured through the Manager field on the User record (the parentsystemuserid column). Setting this field connects users into a tree.

Configuring the Position Hierarchy

Position-based hierarchy is more flexible for organizations where reporting lines don't match management chains. Navigate to the same Hierarchy security settings and select Position hierarchy instead.

You then create Position records (in the model-driven app or via import) and structure them into their own tree using their self-referential parent relationship. Users are then associated with positions via their User record. A user at a "Regional Director" position gains visibility into records owned by users at positions that are below "Regional Director" in the position tree.

This is particularly useful when:

• Your org chart doesn't match your data access needs
• Users need to be at multiple levels simultaneously (a position tree can be more nuanced than manager-reportee chains)
• You're modeling matrix organizations where dotted-line relationships matter

What Records Does Hierarchy Security Expose?

This is where precision matters. When hierarchical security is enabled and a manager (call them Alice) looks at a list view for a table where their security role grants them "Business Unit" level access, Dataverse extends that access to include records owned by users who report to Alice (up to the configured depth) — even if those users are in different business units.

Crucially: this is additive. Alice still sees everything she'd see under her base security role. Hierarchy security only ever adds access; it never removes it. And it only adds access down the reporting chain, never up.

The access Alice gains through hierarchy security is equivalent to read and append access for most configurations. Write, delete, and share permissions don't automatically flow through the hierarchy — those require explicit privilege grants in the security role.

Hierarchy Security vs. Team-Based Access

For many scenarios, team-based access (assigning records to an owner team, then controlling team membership) provides a more predictable and auditable access model than hierarchy security. Hierarchy security is powerful when:

• Your org structure maps cleanly to data ownership
• You need dynamic access adjustment as people move in the org chart
• You're dealing with large user populations where manually maintaining team membership is impractical

If your organization's management hierarchy frequently changes, be aware that reconfiguring the Manager field on user records immediately changes what those managers can access — there's no staging or review step.

---

Using Hierarchy-Aware Query Operators

Once a hierarchy relationship is designated, the Dataverse query engine understands tree traversal. This unlocks powerful query patterns that would otherwise require multiple round-trips or complex client-side logic.

FetchXML: The `Under` Condition

The Under operator retrieves all records that are descendants of a given record in the designated hierarchy. Given a root node's GUID, Under walks the tree depth-first and returns every record at any level below that root.

<fetch>
  <entity name="crf_organizationalunit">
    <attribute name="crf_name" />
    <attribute name="crf_parentunitid" />
    <filter>
      <condition attribute="crf_parentunitid"
                 operator="under"
                 value="{ROOT-UNIT-GUID}" />
    </filter>
  </entity>
</fetch>

The EqualOrUnder variant includes the root node itself in the results:

<condition attribute="crf_parentunitid"
           operator="eq-or-under"
           value="{ROOT-UNIT-GUID}" />

And NotUnder returns records that are not descendants of the specified node:

<condition attribute="crf_parentunitid"
           operator="not-under"
           value="{ROOT-UNIT-GUID}" />

Web API: The `Under` Query Filter

The same operator is available in OData-style Web API queries:

GET [environment]/api/data/v9.2/crf_organizationalunits
  ?$select=crf_name,_crf_parentunitid_value
  &$filter=Microsoft.Dynamics.CRM.Under(
    PropertyName='crf_parentunitid',
    PropertyValue='{ROOT-UNIT-GUID}'
  )

This is significantly more capable than trying to implement tree traversal in client-side code. Without hierarchy operators, fetching an entire subtree requires either recursive API calls (slow, chatty) or a pre-computed depth/path column strategy.

Security-Aware Operators: `EqualUserOrUserHierarchy`

These operators are specifically designed for security filtering. They resolve relative to the currently executing user rather than a hard-coded GUID:

• eq-userid — records owned by the current user
• eq-useroruserhierarchy — records owned by the current user or by users below them in the hierarchy
• eq-useroruserhierarchyandteams — same as above, plus records owned by teams the current user belongs to

<fetch>
  <entity name="crf_serviceorder">
    <attribute name="crf_name" />
    <attribute name="ownerid" />
    <filter>
      <condition attribute="ownerid"
                 operator="eq-useroruserhierarchy" />
    </filter>
  </entity>
</fetch>

This pattern is invaluable for building custom dashboards or reports that should automatically scope to a manager's purview without hardcoding GUIDs or requiring separate views per person.

---

Rollup Columns and Hierarchy: The Aggregation Story

Formula Columns and Rollup Columns in Dataverse: Calculated Data Without Code covers rollup columns in depth, but let's address how they interact specifically with hierarchical structures.

Dataverse rollup columns can aggregate values across child records in a one-to-many relationship. For example, on a Project table you might roll up the sum of estimated hours from all related Task records. This works through a standard one-to-many relationship — not through the hierarchy designation.

Rollup Columns Do Not Traverse the Hierarchy Automatically

This is a critical distinction. A rollup column on Organizational Unit that sums a revenue field from related Service Orders will aggregate direct child relationships only — it will not walk the hierarchy tree and aggregate across all descendants.

If you need a true hierarchical rollup (aggregate all the way down the tree), you have three architectural options:

Option 1: Scheduled Power Automate flows. Build a flow that runs nightly, traverses the hierarchy using the Under operator, and writes an aggregated value back to each node. This works well for daily-refresh scenarios and avoids real-time computation costs.

Option 2: Plugin-based real-time rollup. Write a synchronous plugin that fires on create/update of the leaf-level records and walks up the parent chain, updating rollup fields on each ancestor. This provides real-time accuracy but adds write latency and requires careful handling of concurrent updates.

Option 3: Pre-computed path columns. Store a materialized path (e.g., /root-guid/child-guid/grandchild-guid/) on each record. This enables efficient subtree queries but requires maintenance whenever records are reparented.

Performance Considerations for Hierarchy Queries

The Under operator triggers a recursive CTE on the underlying SQL database. For shallow, sparse hierarchies (say, 5 levels deep with fewer than 10,000 total nodes), this is fast. For deep, dense hierarchies, the performance degrades non-linearly.

Dataverse has a built-in depth limit on hierarchy queries: 100 levels maximum. Hitting this limit throws an error rather than returning partial results. In practice, if your legitimate business hierarchy exceeds 20-30 levels, reconsider your data model — you may be conflating structural depth with data volume.

The Dataverse query engine also supports indexing on the designated hierarchy relationship's lookup column. Ensure the column is indexed (it will be by default for designated hierarchy relationships), and monitor query execution using Auditing and Change Tracking in Dataverse for Compliance to identify queries that scan rather than seek.

---

Hierarchy Visualizations in Model-Driven Apps

The hierarchy visualizer is a built-in control in model-driven apps that renders the tree graphically. It's available on any table that has a designated hierarchy relationship. But getting it configured meaningfully requires several deliberate steps.

Enabling the Hierarchy View

The visualizer is surfaced through a special view type: the Hierarchy View. To configure it:

1. Navigate to your table in the solution explorer (classic mode — the modern maker portal doesn't expose all hierarchy view options yet as of 2025).
2. Expand Hierarchy Settings.
3. Create a new Hierarchy Setting for the table, specifying which self-referential relationship is the designated hierarchy (this should already match your designated relationship).
4. Define the Quick View Form that appears in the tile cards of the hierarchy visualizer. This is a lightweight form that shows key information for each node when browsing the tree.

The Quick View Form approach is essential — without it, the hierarchy tiles just show the record name, which is often insufficient context. Add 2-3 key fields (status, assigned user, a key metric) to make the tiles meaningful.

For more on Quick View Forms and how they render in model-driven apps, see Designing Model-Driven Forms: Sections, Tabs, Subgrids, and Quick View Forms.

Accessing the Visualizer from a View

In the model-driven app, when a user is on a view for a table with hierarchy settings configured, they'll see a Hierarchy button in the command bar (it may appear as a tree icon or under a menu depending on the app version). Clicking it switches from the standard list view to the hierarchy tree view.

The hierarchy tree renders from a root node. If the user is looking at a specific record, the visualizer shows that record's subtree. From a list view, the visualizer shows all root nodes (records with no parent) and allows expanding each.

Configuring the Quick View Form for Hierarchy Tiles

Navigate to the Forms area of your table and create a new Quick View form (not a Main form). Design it with the 2-4 most important fields for at-a-glance hierarchy browsing. For an Organizational Unit, this might be:

• Unit Name (already shown in the title)
• Unit Manager (lookup to User)
• Status (choice column — Active/Inactive/On Hold)
• Total Active Headcount (rollup column)

Keep the Quick View form narrow — it renders inside a fixed-size tile in the hierarchy visualizer. Avoid long text fields, subgrids, or rich text columns. The tile format clips content that overflows.

Link this Quick View form in the Hierarchy Settings configuration. Once published, the tiles in the hierarchy visualizer will show this contextual information for each node.

Limitations of the Built-In Visualizer

The built-in hierarchy visualizer has real limitations you need to communicate to stakeholders:

• It renders a tree, not a directed acyclic graph. Each record can only appear once (under its single parent). If your data has any records with multiple parents (which a hierarchy relationship shouldn't, but data quality issues happen), the visualizer will either error or show the record under only one parent.
• The visualizer doesn't support drag-and-drop reparenting. Users must open a record and change the lookup field manually.
• Print and export from the visualizer is limited — for formal org chart exports, you'll need a PCF control or integration with Visio/Power BI.
• The visualizer loads nodes lazily (expanding level by level), which is good for performance but means there's no "expand all" button. For large trees, navigating is manual and slow.

For organizations that need richer hierarchy visualization — swimlane org charts, interactive node editing, custom node coloring based on record data — consider a custom PCF control. The Extending Model-Driven Apps with PCF Controls: Building and Deploying Custom Field and Dataset Components for Dataverse Forms and Views lesson walks through the PCF architecture.

---

Designing Multi-Level Hierarchies: Architectural Trade-offs

Now we return to the scenario from the introduction: a field service firm with regions, districts, teams, and work orders. You need to model multiple levels of an organizational structure. Dataverse's hierarchy designation is limited to self-referential tables. What are your options?

Option A: Single Self-Referential Table with a Level Column

Flatten all organizational levels into one Organizational Unit table. Add a crf_level choice column with values: Region, District, Team. The hierarchy relationship points from each record to its parent of any level.

Advantages:

• Full hierarchy designation benefits: Under queries, hierarchy security, the visualizer
• Single table to maintain, report against, and secure
• Hierarchy can accommodate irregular depth (some regions might have districts, others go directly to teams)

Disadvantages:

• Validation logic must enforce level consistency (a Team shouldn't be a parent of a Region)
• Views and forms may need filtering by level type to avoid showing all records in undifferentiated lists
• Reporting tools that expect structured columns per level (like most BI tools) will need extra transformation

Option B: Separate Tables per Level

Create Region, District, Team tables with lookup relationships connecting them in a chain: Team → District, District → Region.

Advantages:

• Schema is self-documenting — the table names make the level obvious
• Each level can have different columns, forms, views, and security roles
• BI tools can join the tables naturally

Disadvantages:

• No Dataverse hierarchy designation — none of these relationships can be designated as a hierarchy because they're cross-table
• Under operator, hierarchy security, and the visualizer are all unavailable
• Querying across the full tree requires multiple API calls or complex joins
• Rollup aggregation across levels requires custom logic

This approach is sometimes called a "ladder" model. It's common, but it sacrifices all of Dataverse's native hierarchy machinery. You'll end up rebuilding that machinery in flows or plugins.

Option C: Hybrid — Self-Referential Hierarchy + Cross-Table Relationships

Use a self-referential Organizational Unit table for the hierarchy (with level designation), and separately maintain specialized tables (like Work Order) that have a lookup to Organizational Unit. This gives you:

• Full hierarchy designation on the Organizational Unit tree
• Domain-specific tables (Work Order, Service Request) with meaningful schemas
• The ability to query "all work orders belonging to org units under District X" via a two-step query: first get all org units under District X using Under, then query work orders filtered by those org unit IDs

The two-step query isn't as elegant as a single hierarchical query, but it's far more capable than the pure cross-table ladder model. For performance-sensitive scenarios, cache the subtree ID list (it changes infrequently) to avoid the first step on every query.

---

Combining Hierarchy Security with Standard Dataverse Security

The interaction between hierarchy security and standard Dataverse Security: Business Units, Security Roles, and Teams requires careful design.

Additive Access, Never Subtractive

Hierarchy security never reduces a user's access. If Alice's security role grants her Organization-level read on Work Orders (she can see all work orders in the tenant), hierarchy security adds nothing on top of that — she already has maximum access. Hierarchy security becomes meaningful when base access is scoped lower: to the User level or Business Unit level.

The typical pattern for hierarchy security to be useful:

• Users' base security roles grant User-level access to records (they only own their own records by default)
• Hierarchy security then extends managers' visible set to include records owned by their reports

If base access is already at Business Unit or Organization level, hierarchy security has no practical effect.

Business Units vs. Manager Hierarchy

These are two orthogonal dimensions of access control. Business Units organize users geographically or functionally, with access scoping to the Business Unit boundary. Manager hierarchy cuts across Business Unit lines — Alice's direct reports may be in different Business Units, and hierarchy security still grants Alice access to their records.

For many enterprise scenarios, this cross-Business-Unit access is exactly what you want: a regional VP overseeing multiple country-level Business Units. But for organizations where Business Unit isolation is a hard security boundary (e.g., for regulatory compliance between subsidiaries), this cross-BU access from hierarchy security can be a problem.

Column-Level Security and Hierarchy

Column-Level Security and Record Sharing in Dataverse operates independently of hierarchy security. Hierarchy security grants record-level access — the ability to see that a record exists and read its standard fields. Column-level security controls whether specific sensitive columns (SSN, salary, performance rating) are visible even when a user has record access.

This layering is important: a manager enabled by hierarchy security to see their reports' records will still be blocked from salary columns if column-level security restricts those fields. Design your column-level security profiles with this in mind — don't assume that hierarchy security implies full field access.

---

Hands-On Exercise

In this exercise, you'll configure a complete hierarchical table, enable hierarchy security, and surface the visualizer in a model-driven app. Work in a Developer environment — do not use a production environment.

Scenario

You're building a Territory Management app for a sales organization. Territories are structured hierarchically: National → Regional → District → Local. You'll model this as a single self-referential Territory table.

Part 1: Create and Configure the Territory Table

1. Create a new custom table named Territory with the schema prefix of your publisher (e.g., crf_territory). Set the primary column to crf_name.

2. Add these additional columns to the table:

   • crf_level — Choice column with values: National, Regional, District, Local
   • crf_annualtarget — Currency column
   • crf_status — Choice column: Active, Inactive

3. Navigate to the Relationships section and add a Many-to-one relationship where the Related table is Territory itself. Name the relationship crf_territory_parentterritory. Name the resulting lookup column crf_parentterritoryid with a display name of "Parent Territory."

4. Set cascade behaviors: Delete = Restrict, Reparent = No Cascade.

5. After saving, return to the relationship and enable the Hierarchical setting. Publish the table.

Part 2: Configure the Hierarchy Settings

1. In the classic solution explorer (navigate via the legacy interface), expand your Territory table and click Hierarchy Settings.

2. Create a new Hierarchy Setting. The hierarchy relationship should auto-populate with crf_territory_parentterritory.

3. Back in the modern maker experience, create a Quick View Form for the Territory table containing: crf_name, crf_level, crf_status, crf_annualtarget. Name this form "Territory Tile."

4. Return to the Hierarchy Setting and set the Quick View Form to "Territory Tile." Save and publish.

Part 3: Add Hierarchy Security Configuration

1. In the Power Platform Admin Center, navigate to your environment → Settings → Users + Permissions → Hierarchy Security.

2. Enable Hierarchy Modeling. Select Manager Hierarchy. Set Depth to 3.

3. Create three test users in your environment (or use existing users). Configure User B as a direct report of User A (set User A as User B's Manager on the User record). Configure User C as a direct report of User B.

4. Assign User A, B, and C security roles that grant User-level access to Territory records.

5. Log in as each user and create one Territory record owned by each user. Verify that logged in as User A, you can see all three Territory records (your own, User B's, and User C's). Logged in as User C, verify you can only see your own record.

Part 4: Test Hierarchy Queries

Using the Power Platform Web API from the browser's address bar or a tool like Postman or the XrmToolBox FetchXML Builder, run this query to retrieve all Territories under a specific root record:

<fetch>
  <entity name="crf_territory">
    <attribute name="crf_name" />
    <attribute name="crf_level" />
    <filter>
      <condition attribute="crf_parentterritoryid"
                 operator="eq-or-under"
                 value="{YOUR-ROOT-TERRITORY-GUID}" />
    </filter>
  </entity>
</fetch>

Create a 3-level deep territory tree (National → Regional → District), put your root National territory's GUID in the query, and verify the results include all levels.

Part 5: Surface the Visualizer in the Model-Driven App

1. Add the Territory table to your model-driven app via the app designer. Create a basic view showing Name, Level, Status, and Parent Territory.

2. Publish the app. Navigate to the Territory view in the app.

3. Look for the Hierarchy view icon in the command bar area. If it doesn't appear, re-publish your Hierarchy Settings, then republish the app.

4. Create at least five territory records with a two-level hierarchy. Switch to the Hierarchy view and verify the tree renders correctly with the Quick View tile showing the configured fields.

---

Common Mistakes and Troubleshooting

"The Hierarchy button doesn't appear in my app"

Check these in order:

• Hierarchy Settings for the table must be saved and published
• The table must have at least one record with a parent relationship established (the visualizer won't render without tree data)
• The app itself must be republished after the hierarchy settings are published
• If using a managed solution, ensure the hierarchy settings are included in the solution layer

"My `Under` query returns no results even though child records exist"

The Under operator queries against the designated hierarchy relationship's column. Verify:

• The correct relationship is marked as hierarchical (check the EntityMetadata via Web API: GET /api/data/v9.2/EntityDefinitions(LogicalName='yourtablename')?$select=HierarchyRelationshipName)
• You're filtering on the correct column (the FK column of the designated relationship, not another self-referential lookup)
• The GUID you're providing in the value attribute is correct

"Hierarchy security doesn't seem to expand access for managers"

Check:

• Hierarchy security must be enabled at the environment level in Admin Center
• The manager chain must be correctly configured on the User record (Manager field populated)
• The manager's base security role must grant User-level (not Business Unit or Organization level) access to the table in question — otherwise hierarchy security has nothing to extend
• The records in question must be owned by the subordinate users, not just created by them (ownership is what hierarchy security tracks)

"A record appears twice in the hierarchy visualizer"

A record in a designated hierarchy table can only have one parent. If a record appears in unexpected places in the visualizer, data integrity is compromised — some process (import, bulk update, plugin) has set contradictory parent values. Use a view filtered to show records where the parent relationship creates a cycle or duplicate path, and correct the data. Consider adding the anti-circular-reference plugin logic described earlier.

"My rollup columns show different values than what I'd expect from the hierarchy"

Remember: standard rollup columns aggregate direct child records from a one-to-many relationship, not the full hierarchy subtree. If you're expecting hierarchical aggregation, you need custom logic. Verify whether you actually need subtree aggregation or just direct-child aggregation before building complex solutions.

---

Summary and Next Steps

You now have a complete picture of how Dataverse hierarchical relationships work — from the metadata designation that unlocks hierarchy-aware queries, through the security model that lets manager access propagate through user chains, to the visualizer control that makes the tree navigable in model-driven apps.

The critical mental models to retain:

• Hierarchy designation is a metadata flag, not a data structure change. It instructs the query engine and security engine to treat a specific self-referential relationship as a tree.
• Hierarchy security is about user ownership chains, not record relationship trees. It answers "which user-owned records can this manager see?" not "which records are children of this record?"
• The Under operator does the heavy lifting for tree traversal queries. Use it in FetchXML and the Web API instead of recursive client-side code.
• Single self-referential table hierarchies preserve all Dataverse hierarchy features. Cross-table ladder models sacrifice them.
• Rollup columns don't traverse hierarchy automatically. Subtree aggregation requires custom logic — flows, plugins, or pre-computed paths.

For next steps, deepen your understanding of the security model by working through Model-Driven App Security: Configuring Security Roles, Field Permissions, and Team-Based Access for Table Data. If you want to extend the hierarchy visualizer with custom rendering, explore Extending Model-Driven Apps with PCF Controls: Building and Deploying Custom Field and Dataset Components for Dataverse Forms and Views. And if you need to import an existing hierarchy structure into Dataverse from a flat file or source system, Importing and Migrating Data into Dataverse: Excel Import, Dataflows, and Upserts covers the patterns for loading parent-child data while preserving referential integrity.
